If necessary, clamp the end of the clutch cable with pliers and tighten the wing nut so that the clutch pedal has a free play of 10-25 mm.
When measuring, press your finger on the side of the pedal, and with the other hand, press the clutch pedal until resistance occurs. With a finger, you can easily determine the reverse (free) pedal stroke.
Free travel a=10-25 mm
After adjustment, make sure that both tabs of the wing nut fit into the recess of the clutch lever.
Press the clutch pedal several times and check its free play again.
Lubricate the threaded portion of the clutch cable, wing nut and thrust ball bearing of the clutch lever with grease.
Install the wheel, lower the vehicle and tighten the wheel bolts to 130 Nm (13.0 kgcm).
